Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch
Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch
Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch
Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch

Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch

Key Features of S310-24P4S:
Model: S310-24P4S
Interface Port Details: 24 x 10/100/1000BASE-T ports, 4 x GE SFP ports
PoE Budget: 400 W
Type: Layer 3 Base Managed Switch
Warranty: 3 Year Brand Warranty
Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch
Based on 0 reviews. - Write a review
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Model: S310-24P4S
attr -Key Feature 2 > Interface Port Details: 24 x 10/100/1000BASE-T ports, 4 x GE SFP ports
attr -Key Feature 3 > PoE Budget: 400 W
attr -Key Feature 4 > Type: Layer 3 Base Managed Switch
attr -Key Feature 5 > Warranty: 3 Year Brand Warranty
Huawei Switch.
Switching Capacity 56 Gbit/s
Packet Forwarding Rate 42 Mpps
GE RJ45 24 (PoE+) (1G/100M/10M)
GE SFP 4 (1G)
Maximum PoE Power Consumption [W] 400
PoE Supported
iStack Up to 4 switches of the same series in a stack
Certification EMC certification, Safety certification, Manufacturing certification
Chassis Material Metal
Static Power Consumption [W] 30.82
Dimensions Without Packaging (H X W X D) [Mm(In.)] Basic dimensions (excluding the parts protruding from the body):
43.6 mm x 442.0 mm x 220.0 mm (1.72 in. x 17.4 in. x 8.66 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel):
43.6 mm x 442.0 mm x 227.0 mm (1.72 in. x 17.4 in. x 8.94 in.)
Dimensions With Packaging (H X W X D) [Mm(In.)] 90.0 mm x 550.0 mm x 360.0 mm (3.54 in. x 21.65 in. x 14.17 in.)
Installation Type Rack mounting, Desk mounting, Wall mounting
Weight Without Packaging [Kg(Lb)] 2.92 kg (6.44 lb)
Weight With Packaging [Kg(Lb)] 3.79 kg (8.36 lb)
Typical Power Consumption [W] 40.07
Maximum Power Consumption [W] - Without PoE: 47.1 W
- Full PoE load: 491.66 W (PoE: 400 W)
Number Of Fans Modules 2
Long-Term Operating Temperature [°C(°F)] -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.)
Long-Term Operating Relative Humidity [Rh] 5% RH to 95% RH, non-condensing
Power Supply Mode AC built-in
Input Voltage Range [V] - AC input: 90 V AC to 290 V AC; 45 Hz to 65 Hz
- High-voltage DC input: 190 V DC to 290 V DC
Power Supply Surge Protection [Kv] Differential mode: ±6 kV
Common mode: ±6 kV
Types Of Fans Built-in
Heat Dissipation Mode Air cooling for heat dissipation, intelligent fan speed adjustment
Airflow Direction Air intake from left and front, air exhaustion from right
Warranty 03-Year Brand Warranty
Description:

Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch

Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch is a better choice for business and enterprise networks, with performance and flexibility being the need of the hour. With a switching capacity of 56 Gbit/s and a packet forwarding rate of 42 Mpps, it supports data transfer with reliability and efficient handling of multiple network processes. The switch comes with 24 GE RJ45 PoE+ ports (10M/100M/1G) and 4 GE SFP uplink ports, offering flexible connection choices for different network scenarios. Power over Ethernet is available with a maximum 400 W PoE budget, and the switch can be employed to power access points, IP cameras, and VoIP phones through network cables. iStack technology allows up to 4 switches of the same series to be stacked, simplifying management and scaling capacity when required.

Made from a tough metal chassis and EMC certified, safe, and built for compliance, the S310-24P4S ensures trouble-free use. Installation is flexible with rack, desk, or wall mounting. The switch measures 43.6 mm x 442.0 mm x 220.0 mm (standard size) and 227.0 mm maximum depth. It weighs 2.92 kg packed out and 3.79 kg packed. With power, it consumes 30.82 W at static load, 40.07 W under normal conditions, and up to 47.1 W without PoE. With a full PoE load, the maximum power consumption is 491.66 W. It supports AC input (90 V–290 V, 45–65 Hz) and high-voltage DC input (190 V–290 V), and also surge protection of ±6 kV in differential and common modes. It has two built-in fan modules to provide air cooling with intelligent speed control. The air intake is optimized from the left and front, and exhaust is to the right. It operates reliably at temperatures between -5°C to +50°C and humidity of 5% to 95% RH, with high reliability for long-term stable operation.

Buy Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch in Bangladesh

You can buy your desired Huawei eKit S310-24P4S 24-Port 10/100/1000BASE-T & 4-Port GE SFP Managed PoE Switch at Global Brand PLC. We are the authorized distributor of Huawei eKit in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
