image of Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point with Spec and Price in BDT

Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point

Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point

Key Features of AP673:

Model: AP673
Details: Settled AP, Wi-Fi 7, 13.66 Gbps device rate, Tri-radio, 26 dBm transmit power, 1 x 100M/GE/2.5GE/5GE electrical port, 1 x 10M/100M/GE electrical port, 1 x USB port, Smart antenna
Coverage range: 40 m optimal
Recommended users: 300 access users recommended (Max. 1024 access users)
Warranty: 3 Year Brand Warranty

Based on 0 reviews. - Write a review

৳0.00

Add to Cart

Specification Description Reviews

Specification:

Key Features
attr - Key Feature 1 >	Model: AP673
attr -Key Feature 2 >	Details: Settled AP, Wi-Fi 7, 13.66 Gbps device rate, Tri-radio, 26 dBm transmit power, 1 x 100M/GE/2.5GE/5GE electrical port, 1 x 10M/100M/GE electrical port, 1 x USB port, Smart antenna
attr -Key Feature 3 >	Coverage range: 40 m optimal
attr -Key Feature 4 >	Recommended users: 300 access users recommended (Max. 1024 access users)
attr -Key Feature 5 >	Warranty: 3 Year Brand Warranty
Huawei Access Point
Wi-Fi Standard	2.4 GHz: 802.11b/g/n/ax/be 5 GHz: 802.11a/n/ac/ac Wave 2/ax/be 6 GHz: 802.11a/ax/be
Installation Type	Wall, Ceiling (Solid Wall/Gypsum Board/Spring Tee/Flat-Edge T-Rail/Channel Rail/Beam/Threaded Rod) Junction Box (86 mm/1-Gang 120 mm/Octagonal/2-Gang 120 mm)
Optimal Signal Distance (M)	40
Max Number Of Access Users	1024
Recommended Number Of Access Users	300
Device Rate	13.66 Gbps
Maximum Number Of Physical Ports On The Entire Device	5GE (RJ45) x 1, 100M/1000M/2500M/5000M auto-sensing GE (RJ45) x 1, 10M/100M/1000M auto-sensing
Radio Number	3
Maximum Channel Bandwidth [Mhz]	Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 80 MHz Radio 2 (6 GHz): 320 MHz
Maximum Transmit Power	2.4 GHz: 20 dBm/chain 23 dBm (combined power) 5 GHz (2x2): 20 dBm/chain 23 dBm (combined power) 6 GHz (4x4): 20 dBm/chain 26 dBm (combined power)
Mimo Spatial Streams	Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2 Radio 2 (6 GHz): 4x4
Maximum Power Consumption [W]	21.1 W (excluding USB)
Input Voltage Range [V]	DC: 12 V ± 10% PoE: 802.3at/af
Dimensions Without Packaging (H X W X D) [Mm(In.)]	Diameter x depth: 220 mm x 45 mm (8.66 in. x 1.77 in.)
Dimensions With Packaging (H X W X D) [Mm(In.)]	72 mm x 260 mm x 255 mm (2.83 in. x 10.24 in. x 10.04 in.)
Weight Without Packaging [Kg(Lb)]	0.745 kg (1.64 lb)
Weight With Packaging [Kg(Lb)]	1.230 kg (2.71 lb)
Long-Term Operating Temperature [°C(°F)]	–10°C to +50°C (14°F to 122°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.] The maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-Term Operating Relative Humidity [Rh]	5% RH to 95% RH (non-condensing)
Radio Interface	Built-in smart antennas
Antenna Gain	2.4 GHz: 4 dBi/chain (peak gain) 2 dBi (combined gain) 5 GHz: 5 dBi/chain (peak gain) 3 dBi (combined gain) 6 GHz: 5 dBi/chain (peak gain) 3 dBi (combined gain)
Operating Frequency Band	2.4GHz,5GHz,6GHz
Warranty	03-Year Brand Warranty

Description:

Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point

Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point is an extreme-speed wireless access point for modern enterprises, schools, and large indoor spaces. It supports the latest Wi-Fi 7 standard in tri-radio mode across 2.4 GHz (802.11b/g/n/ax/be), 5 GHz (802.11a/n/ac/ac Wave 2/ax/be), and 6 GHz (802.11a/ax/be) frequencies and supports a total device rate of up to 13.66 Gbps. It possesses an optimal range of 40 meters for its signal and delivers fast and stable connectivity across large coverage areas.

The AP673 supports a maximum of 1024 users, with the optimum being 300 for the greatest performance. It possesses three radios, including 2x2 MIMO on 2.4 GHz, 2x2 MIMO on 5 GHz, and 4x4 MIMO on 6 GHz. 40 MHz maximum channel bandwidths for 2.4 GHz, 80 MHz for 5 GHz, and 320 MHz for 6 GHz enable extensive coverage. Transmit power is 23 dBm combined for 2.4 GHz, 23 dBm combined for 5 GHz, and 26 dBm combined for 6 GHz to ensure extensive and trustworthy coverage. Internal smart antennas enhance signal quality with 4 dBi per chain on 2.4 GHz and 5 dBi per chain on 5 GHz and 6 GHz antenna gains.

The device supports one 5GE auto-sensing RJ45 interface and one GE auto-sensing RJ45 interface for flexible network and uplink settings. Power is provided via 802.3at/af PoE or a 12 V DC power input. The maximum power consumption is 21.1 W minus USB. Its small form factor is 220 mm in diameter and 45 mm in depth, weighing 0.745 kg. It offers wall, ceiling, and junction boxes in a variety of sizes. Its operational temperature is between –10°C and +50°C, and humidity of 5% to 95% non-condensing. Huawei AP673, with Wi-Fi 7 technology, tri-radio capability, and smart antenna architecture, offers secure, high-bandwidth wireless performance for high-usage indoor networks.

Buy Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point in Bangladesh

You can buy your desired Huawei AP673 Wi-Fi 7 Tri-Radio Smart Antenna Managed PoE Settled/Ceiling Access Point at Global Brand PLC. We are the authorized distributor of Huawei eKit in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
