Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch
Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch
Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch
Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch
Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch

Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch

Key Features of S620-24T16X8Y2CZ:
Model: S620-24T16X8Y2CZ
Details: 24 x 10/100/1000M BASE-T ports, 16 x 10GE SFP+ ports, 8 x 25GE SFP28 ports, 2 x 40GE/100GE QSFP28 | Packet forwarding rate: 867 Mpps | Switching capacity: 1168 Gbit/s
PoE Budget: Not Applicable
Type: Layer 3 Standard Switch
Warranty: 3 Year Brand Warranty
Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch
Based on 0 reviews. - Write a review
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Model: S620-24T16X8Y2CZ
attr -Key Feature 2 > Details: 24 x 10/100/1000M BASE-T ports, 16 x 10GE SFP+ ports, 8 x 25GE SFP28 ports, 2 x 40GE/100GE QSFP28 | Packet forwarding rate: 867 Mpps | Switching capacity: 1168 Gbit/s
attr -Key Feature 3 > PoE Budget: Not Applicable
attr -Key Feature 4 > Type: Layer 3 Standard Switch
attr -Key Feature 5 > Warranty: 3 Year Brand Warranty
Huawei Switch.
Switching Capacity 1168 Gbit/s
Packet Forwarding Rate 867 Mpps
25G SFP28 8 (25G/10G/2.5G/1G)
GE RJ45 24 (1G/100M/10M)
100G QSFP28 2 (100G/40G)
10G SFP+ 16 (10G/2.5G/1G/100M)
iStack Up to 9 switches of the same series in a stack
Number of Card Slots 1
Number of Power Slots 2
Certification EMC certification, Safety certification, Manufacturing certification
Chassis Material Metal
Static Power Consumption [W] 77
Dimensions Without Packaging (H X W X D) [Mm(In.)] Basic dimensions (excluding the parts protruding from the body):
43.6 mm x 442.0 mm x 420.0 mm (1.72 in. x 17.40 in. x 16.54 in.)

Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel):
43.6 mm x 442.0 mm x 454.0 mm (1.72 in. x 17.4 in. x 17.87 in.)
Dimensions With Packaging (H X W X D) [Mm(In.)] 145.0 mm x 650.0 mm x 550.0 mm (5.71 in. x 25.59 in. x 21.65 in.)
Installation Type Rack mounting, Desk mounting
Weight Without Packaging [Kg(Lb)] 6.31 kg (13.91 lb)
Weight With Packaging [Kg(Lb)] 8.76 kg (19.31 lb)
Typical Power Consumption [W] 30% traffic under the ATIS standard and dual power modules: - 122 W (with two 180 W AC power modules) - 118 W (with two 240 W DC power modules)
Maximum Power Consumption [W] 100% traffic under the ATIS standard and dual power modules: - 127 W (with two 180 W AC power modules) - 123 W (with two 240 W DC power modules)
Number Of Fans Modules 2
Long-Term Operating Temperature [°C(°F)] –5°C to +45°C (23°F to 113°F) at an altitude of 0 to 1800 m (0 to 5905.44 ft.)
Long-Term Operating Relative Humidity [Rh] 5% RH to 95% RH, non-condensing
Power Supply Mode Pluggable power supply
Input Voltage Range [V] - AC input: 90 V AC to 290 V AC; 45 Hz to 66 Hz - High-voltage DC input: 190 V DC to 290 V DC - DC input: -38.4 V DC to -72 V DC
Power Supply Surge Protection [Kv] - Configured with AC power modules: ±6 kV in differential mode and ±6 kV in common mode - Configured with DC power modules: ±2 kV in differential mode and ±4 kV in common mode
Types Of Fans Pluggable
Heat Dissipation Mode Air cooling for heat dissipation, intelligent fan speed adjustment
Airflow Direction Air intake from front and right and air exhaust from rear
Redundant Power Supply 1+1 Pluggable AC and DC power modules can be used together on the same device. Note: Power modules with fans and power modules without fans cannot be installed on the same device.
Warranty 03-Year Brand Warranty
Description:

Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch

Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch is designed for high-performance enterprise networks, data centers, and aggregation layers. With a switching capacity of 1168 Gbit/s and a packet forwarding rate of 867 Mpps, it delivers strong performance for heavy workloads and large-scale traffic. It features rich connectivity through 24 GE RJ45 ports, 16×10GE SFP+ ports, 8×25GE SFP28 ports, and 2×40GE/100GE QSFP28 uplink ports, making it deployable at different network speeds. It is built with iStack technology to allow a cluster of the same series switches up to 9 to act as one system for simplicity in management and expansion.

The architecture includes 1 card slot and 2 power slots, with AC and DC power modules that can be plugged in. A redundant 1+1 power supply is included, offering high availability. Power consumption is minimal, with typical consumption of 122 W (dual AC) or 118 W (dual DC) at 30% traffic, and maximum consumption of 127 W (dual AC) or 123 W (dual DC) at full load. Static consumption is 77 W. Surge protection is ±6 kV for AC input and up to ±4 kV for DC input.

Cooling is 2 pluggable fan modules with intelligent speed control, via front and right air intake and rear exhaust. The metal chassis measures 43.6 mm × 442.0 mm × 420.0 mm (basic) and 454.0 mm (max depth), and weighs 6.31 kg unpackaged and 8.76 kg packaged. The Huawei eKit S620-24T16X8Y2CZ is a rack-mountable or desktop-mounted switch with a temperature of –5°C to +45°C and humidity of 5% to 95% RH. Providing EMC, safety, and manufacturing certifications, the switch offers stable high-speed switching for enterprise and data center networks.

Buy Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch in Bangladesh

You can buy your desired Huawei eKit S620-24T16X8Y2CZ 24-Port 10/100/1000M & 16-Port 10GE SFP+ & 8-Port 25GE SFP28 & 2-Port 40GE/100GE QSFP28 Managed Non-PoE Switch at Global Brand PLC. We are the authorized distributor of Huawei eKit in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
