Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera
Key Features of IPC815SB-ADF14K-I0:High quality image with 5MP, 1/2.8"CMOS sensor |
120dB true WDR technology enables clear images in the strong light scene |
Built-in 2 Mic, Supports the detection of sounds over longer distances |
Smart IR, up to 10m (33ft) IR distance |
Supports 256 G Micro SD card |
CALL FOR DETAILS: +880 1729-200300, +880 1969-633163 |
Key Features | |
attr - Key Feature 1 > | High quality image with 5MP, 1/2.8"CMOS sensor |
attr -Key Feature 2 > | 120dB true WDR technology enables clear images in the strong light scene |
attr -Key Feature 3 > | Built-in 2 Mic, Supports the detection of sounds over longer distances |
attr -Key Feature 4 > | Smart IR, up to 10m (33ft) IR distance |
attr -Key Feature 5 > | Supports 256 G Micro SD card |
Call Info > | CALL FOR DETAILS: +880 1729-200300, +880 1969-633163 |
General | |
Brand | Uniview |
Model | IPC815SB-ADF14K-I0 |
Type | 5MP Fisheye Fixed Dome Network IP Camera |
Camera | |
Sensor | 1/2.8", progressive scan, 5.0 megapixel, CMOS |
Min. Illumination | Color: 0.01 lux (F2.0, AGC ON) 0 lux with IR |
Day/Night | IR-cut filter for day & night function |
Shutter | Auto/Manual, shutter time: 1~1/100000 s |
WDR | 120dB |
S/N | >55dB |
Lens | |
Angle of view | 360° |
Lens type | 1.4mm@F2.0 |
Iris | Fixed |
DORI | |
DORI Distance | Lens: 1.4mm Detect (m): 31.5 Observe (m): 12.6 Recognize (m): 6.3 Identify (m): 3.2 |
Illuminator | |
IR Range | UP to 10m (33ft) |
Wavelength | 850nm |
IR On/Off Control | Auto/Manual |
Storage | |
Edge Storage | Micro SD, up to 256GB |
Network Storage | ANR, NAS(NFS) |
Video | |
Frame rate | Main Stream: 5MP (2592*1944): Max.30fps Sub Stream: 1080P (1920*1080): Max.30fps; 720P (1280*720), Max 30fps Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps |
H.264 Code Profile | Baseline profile, Main Profile, High Profile |
Video Compression | Ultra 265, H.265, H.264, MJPEG |
Video Bit Rate | 128 Kbps~16 Mbps |
U-code | Support |
OSD | Up to 8 OSDs |
Privacy Mask | Up to 4 areas |
ROI | Up to 8 areas |
Video stream | Triple streams |
Image | |
Digital Noise Reduction | 2D/3D DNR |
White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Smart IR | Support |
Flip | Normal/Flip Vertical/ Flip Horizontal/180° |
Dewarping | N/A |
HLC | N/A |
BLC | Support |
Defog | Digital Defog |
Audio | |
Audio Compression | G.711 |
Audio Bitrate | 64 Kbps |
Two-way Audio | Supported |
Suppression | Supported |
Sampling Rate | 8 KHZ |
Events | |
Basic Detection | Motion detection, tampering alarm, audio detection, heat map |
General Function | Watermark, IP Address Filtering, Tampering Alarm, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
Interface | |
Video Output | N/A |
RS485 | N/A |
Audio I/O | Input: impedance 35 kΩ; amplitude 2 V [p-p] Output: impedance 600 Ω; amplitude 2 V [p-p] |
Alarm I/O | 1/1 |
Built-in Mic | Supported 2 |
Built-in Speaker | N/A |
WIFI | N/A |
Network | 1 * RJ45 10M/100M Base-TX Auto-adaptive Ethernet |
Network | |
Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSH |
Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API,SDK |
User/Host | Up to 32 users. 2 user levels: administrator and common user |
Security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic and digest authentication for RTSP, Digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF |
Client | EZStation EZView EZLive |
Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+ |
Power | |
Power Interface | Ø 5.5mm coaxial power plug |
Power | DC12V±25%,PoE (IEEE 802.3af) Power consumption: Max. 8.5W |
Operating Environment | |
Surge Protection | 4KV |
Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Storage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
Physical Specification | |
Dimensions | Φ125 × 43.7 mm (Φ4.9" × 1.7") |
Weight | 0.36kg (0.79lb) |
Body Material | Metal + Plastic |
Certification | |
EMC | CE-EMC (EN 55032: 2015+A1:2020,EN 61000-3-3: 2013+A1: 2019,EN IEC 61000-3-2: 2019+A1: 2021,EN 55035: 2017+A11:2020) FCC (FCC CFR 47 part15 B, ANSI C63.4-2014) |
Safety | CE LVD (EN 62368-1:2014+A11:2017) CB (IEC 62368-1:2014) UL (UL 62368-1, 2nd Ed., Issue Date: 2014-12-01) |
Environment | CE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
Protection | IP66 (IEC 60529:1989+AMD1:1999+AMD2:2013) IK10 (IEC 62262:2002) |
Additional | |
Reset Button | Supported |
Warranty | |
Warranty Details | 1-Year Brand Warranty |
Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera
Uniview IPC815SB-ADF14K-I0, a robust 5MP Fisheye Fixed Dome Network IP Camera engineered for dependable and comprehensive surveillance. Featuring a high-quality 5MP image captured by a 1/2.8" CMOS sensor, this camera delivers sharp and detailed visuals with resolutions of 2592 x 1944 pixels at 30/25fps. Utilizing cutting-edge compression technologies such as Ultra 265, H.265, H.264, and MJPEG, the IPC815SB-ADF14K-I0 optimizes storage efficiency without compromising image quality. The camera's 120dB true WDR technology ensures clear imaging even in strong light scenes, enhancing its performance in challenging lighting conditions.
Equipped with built-in dual microphones, this fisheye camera supports the detection of sounds over longer distances, providing an additional layer of audio surveillance. The camera's comprehensive set of features includes 1 alarm input and 1 output, as well as 1 audio input and 1 output, offering versatile integration capabilities. With Smart IR technology providing up to 10m (33ft) IR distance, support for a 256 G Micro SD card for convenient local storage, IK10 vandal resistance, IP66 protection against the elements, and compatibility with PoE power supply, the IPC815SB-ADF14K-I0 stands as a reliable choice for diverse surveillance needs. Backed by a 1-year brand warranty, this fisheye fixed dome camera ensures durability and performance, making it an ideal solution for essential surveillance applications without unnecessary embellishments.
What is the Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera price in Bangladesh?
Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera price in Bangladesh is BDT to be decided. At Global Brand, we are committed to providing our customers with the best shopping experience. With our affordable prices and top-notch customer service, you can be confident that you're making the right choice. .
Where to buy authentic Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera in Bangladesh?
You can buy 100% authentic Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera from our online shop or in-person at our branch. Shop with confidence and take advantage of free delivery when you buy from our online shop.
By visiting this page you can explore about Features, Specification, Description, Reviews & Latest price of Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera in BDT as well you can buy online IPC815SB-ADF14K-I0 with best price. The Uniview IPC815SB-ADF14K-I0 5MP Fisheye Fixed Dome Network IP Camera is available in Bangladesh for the following price: to be decided.Take advantage of our free delivery and don't miss out on the opportunity to buy IPC815SB-ADF14K-I0 online at the best price in Bangladesh!
