Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point
Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point
Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point
Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point

Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point

Key Features of AP162E:
Model: AP162E
Details: Wall plate 86x86 AP | Wi-Fi 6 | 2.975 Gbps device rate | Dual-radio | Smart antenna
Coverage Range: 15 m optimal
Recommended users: 48 users, but Max. 128 access users
Warranty: 3 Years Brand Warranty
Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point
Based on 0 reviews. - Write a review
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Model: AP162E
attr -Key Feature 2 > Details: Wall plate 86x86 AP | Wi-Fi 6 | 2.975 Gbps device rate | Dual-radio | Smart antenna
attr -Key Feature 3 > Coverage Range: 15 m optimal
attr -Key Feature 4 > Recommended users: 48 users, but Max. 128 access users
attr -Key Feature 5 > Warranty: 3 Years Brand Warranty
Huawei Access Point
Wi-Fi Standard 2.4 GHz: 802.11b/g/n/ax
5 GHz: 802.11a/n/ac/ac Wave 2/ax
Installation Type Junction Box (86 mm)
Optimal Signal Distance (M) 15
Max Number Of Access Users 128
Recommended Number Of Access Users 48
Device Rate 2.975 Gbps
Maximum Number Of Physical Ports On The Entire Device GE (RJ45) x 2, 10M/100M/1000M auto-sensing
Radio Number 2
Maximum Channel Bandwidth [Mhz] Radio 0 (2.4 GHz): 40 MHz
Radio 1 (5 GHz): 160 MHz
Maximum Transmit Power 2.4 GHz: 17 dBm/chain 20 dBm (combined power)
5 GHz: 17 dBm/chain 20 dBm (combined power)
Mimo Spatial Streams Radio 0 (2.4 GHz): 2x2
Radio 1 (5 GHz): 2x2
Maximum Power Consumption [W] 9.1
Input Voltage Range [V] PoE: 802.3af
Dimensions Without Packaging (H X W X D) [Mm(In.)] 86 mm x 86 mm x 42.5 mm (3.39 in. x 3.39 in. x 1.67 in.)
Dimensions With Packaging (H X W X D) [Mm(In.)] 98 mm x 117 mm x 73 mm (3.86 in. x 4.61 in. x 2.87 in.)
Weight Without Packaging [Kg(Lb)] 0.14 kg (0.31 lb)
Weight With Packaging [Kg(Lb)] 0.24 kg (0.53 lb)
Long-Term Operating Temperature [°C(°F)] 0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.]
The maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)
Long-Term Operating Relative Humidity [Rh] 5% RH to 95% RH, non-condensing
Radio Interface Built-in smart antennas
Antenna Gain 2.4 GHz: 3 dBi/chain (peak value) 3 dBi (combined gain)
5 GHz: 2 dBi/chain (peak value) 1 dBi (combined gain)
Operating Frequency Band 2.4GHz,5GHz
Warranty 03-Year Brand Warranty
Description:

Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point

Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point is a wireless solution designed for small offices, homes, and indoor spaces requiring reliable network coverage. Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point features support of Wi-Fi 6 technology with dual-band operation on 2.4 GHz (802.11b/g/n/ax) and 5 GHz (802.11a/n/ac/ac Wave 2/ax), with a maximum combined device rate of 2.975 Gbps. With a best signal distance of 15 meters, it provides reliable wireless links to multiple devices in a compact coverage area.

The AP162E provides up to 128 users, with 48 recommended for ensured performance. It has two radios with 2x2 MIMO on 2.4 GHz and 5 GHz bands. Maximum channel bandwidth of 40 MHz on 2.4 GHz and 160 MHz on 5 GHz. The maximum transmit power is 20 dBm combined on both frequencies, providing strong coverage in small rooms. Smart antennas are integrated to enhance signal quality by 3 dBi per chain at 2.4 GHz and 2 dBi per chain at 5 GHz.

Wired connectivity is supported by two GE auto-sensing RJ45 ports (10M/100M/1000M). Power is supplied through 802.3af PoE, and the maximum power consumption is 9.1 W. AP162E is appropriate for mounting on a junction box (86 mm) and has dimensions of 86 × 86 × 42.5 mm and a light weight of 0.14 kg without packaging. Working temperature ranges from -0°C to 40°C and 5% to 95% relative humidity, with reliable operation in indoor environments. With two radios, Wi-Fi 6 support, and smart antennas, the Huawei eKit AP162E provides fast and reliable wireless coverage for small offices, indoor spaces, and multiple users, and simple, flexible installation in junction boxes.

Buy Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point in Bangladesh

You can buy your desired Huawei eKit AP162E Wi-Fi 6 Wall Plate Dual-Radio Managed PoE Access Point at Global Brand PLC. We are the authorized distributor of Huawei eKit in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
