image of Cudy WR1500 AX1500 Dual-Band Wi-Fi 6 Mesh Router & Power Guard ECO-430-PRO Mini DC UPS (With free X-PON ONU) with Spec and Price in BDT

Cudy WR1500 AX1500 Dual-Band Wi-Fi 6 Mesh Router & Power Guard ECO-430-PRO Mini DC UPS (With free X-PON ONU)

Key Features of WR1500 & ECO-430-PRO:
Cudy 4-Stream Dual-Band Wi-Fi 6 (1201 Mbps + 300 Mbps) Mesh Router
Covers Up to 100m² (1,100 ft²) with Up to 60 Connected Devices
4× Gigabit Ethernet Ports
Power Guard High-Capacity 8000mAh Battery with 4–8 Hours Backup
Multi-Voltage & Multi-Port Output with POE Support

CALL FOR DETAILS: +8801969-633131
Cudy WR1500 AX1500 Dual-Band Wi-Fi 6 Mesh Router & Power Guard ECO-430-PRO Mini DC UPS (With free X-PON ONU)
Based on 0 reviews. - Write a review
৳6,150.00
৳7,550.00
Add to Cart
Buy Now
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Cudy 4-Stream Dual-Band Wi-Fi 6 (1201 Mbps + 300 Mbps) Mesh Router
attr -Key Feature 2 > Covers Up to 100m² (1,100 ft²) with Up to 60 Connected Devices
attr -Key Feature 3 > 4× Gigabit Ethernet Ports
attr -Key Feature 4 > Power Guard High-Capacity 8000mAh Battery with 4–8 Hours Backup
attr -Key Feature 5 > Multi-Voltage & Multi-Port Output with POE Support
Call Info >

CALL FOR DETAILS: +8801969-633131
Cudy Router
Router Brand: Cudy
Model: WR1500 1.0
Type: AX1500 Wi-Fi 6 Router

Hardware Specifications:

CPU: Chipset: RTL8197H
CPU Details: 1 GHz CPU

Memory/Storage:
- Flash/ROM: 16 MB (128 Mbit) NOR
- DDR/RAM: 128 MB (1 Gbit) DDR2

Wireless:
5 GHz Wi-Fi Speed: 1201 Mbps
2.4 GHz Wi-Fi Speed: 300 Mbps
5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 4× Fixed

Interfaces:
Gigabit RJ45 Ports: 4
Ethernet Notes: 1× WAN port, the rest are LAN ports
LED: System
Physical Buttons: WPS Button, Reset Button
Power Input: DC Jack

Power:
Power Methods: DC
DC: 12V 1A
Power Adapter: Input: 100 ~ 240 V, 50/60 Hz AC. Output: 12V 1A DC
Max Power Consumption (W): 10W

Reliability:
Environment:
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 95% non-condensing

Mechanical:
- Installation:
Desktop
Wall-mount

- Dimension:
183.3×109×35 mm
7.22×4.29×1.38 inches

- Product Weight:
EU: 220 g (7.76 oz.)
ZH: 224.6 g (7.92 oz.)

Software Specifications:
- Wireless:
Wi-Fi Standards: Wi-Fi 6
Max Wi-Fi Modulation: 1024-QAM

- Wi-Fi Efficiency:
OFDMA
MU-MIMO
BSS Color

Max Capacity: 128
Recommended Client Upper Limit: 60
Max Wi-Fi Channel Width: 80 MHz
Wi-Fi Security: WPA/WPA2/WPA3
WPS: True

General:
Operation Modes:
Wi-Fi Router
Access Point
Range Extender
WISP
Client

Mesh: Cudy Mesh

Mesh Backhaul:
Wireless Backhaul
Wired Backhaul

WAN Mode:
DHCP
Static IP
PPPOE
PPTP
L2TP

Network:
QoS: Per-User Rate Limiting
DHCP: Server
IP Versions: IPv4/IPv6

IPv6 Protocols:
Relay
Dynamic (SLAAC/DHCPv6)
Static (Fixed IP)
Passthrough
464XLAT
MAP-E
DS-Lite

IPTV/VLAN:
Tag VLAN
IPTV VLAN
VoIP VLAN
Bridge

IGMP: IGMP Proxy

Forwarding:
Port Forwarding
UPnP
DMZ

Firewall:
SPI Firewall
Block PING

Utilities:
VPN Client:
PPTP
L2TP
Wireguard

DNS Options: Manual DNS
Online Detection: True

Management:
- All Devices Management:
MAC Filter
IP/MAC Binding

- Content Management:
Domain Filter
IP Filter
Port Filter

System:
- Local Control Method: Config Web Page

- Remote Control Method:
TR069/TR098/TR111/TR181
Config Page via HTTP

Firmware Upgrade: Local Update
Reliability: Backup and Restore

- Languages:
English
Portuguese Russian
Spanish
Ukrainian
French
Simplified Chinese

Additional:
- Included in the Box:
WR1500
Power Adapter
Ethernet Cable
Installation Guide

Certification: FCC, CE
Power Guard UPS
UPS Brand: Power Guard
Model: ECO-430-PRO
Type: Mini DC UPS

- Battery:
Battery Capacity: 2000mAh*4 LiFeP04 (8000mAh)
Backup Time: Extended power backup capacity of up to 4-8 hours, depending on your device’s power consumption.
Charging Time: Typical: 2-3 Hours

- Power:
Input Voltage: 100-240Vac /50Hz-60Hz
Output Power (Max.): 30W

- Output Voltage (Selectable):
USB interface: 5V DC
DC interface: 9V DC | 12V DC
POE interface: 15V DC | 24V DC

- Output Polarity:
USB interface: Standard
DC interface: --€- +
POE interface: +4,5pins -7,8pins

- Output Power & Current (In Common):
USB interface: 2.0A | 10W
DC interface: 2.0A/9W | 2.0A / 12W
POE interface: 1.0A/(15V/15W) | (24V/24W)

- Physical Specification:
Dimensions: 159*104*28 mm
Weight: 0.4 kg

- Additional:
LED Indicator: Yes
Temperature: O°C-40°C
Humidity: 20%-90%
Noise Level: Less than 40dB
Warranty
Warranty Details 01-Year Brand Warranty
