CUDY POE200 30W Gigabit PoE+ Injector
CUDY POE200 30W Gigabit PoE+ Injector
CUDY POE200 30W Gigabit PoE+ Injector

CUDY POE200 30W Gigabit PoE+ Injector

Key Features of POE200:
Complies with IEEE 802.3af/at Standards
Up to 30W Power Output (44v ~ 50v), Ideal for PoE+ Devices
Supports 100-Meter Transmission Distance
Works with IP Cameras, VoIP Phones, and Wi-Fi APs
Over-Current, Over-Voltage, Overload, and Anti-Interference Protection
CUDY POE200 30W Gigabit PoE+ Injector
Based on 0 reviews. - Write a review
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > Complies with IEEE 802.3af/at Standards
attr -Key Feature 2 > Up to 30W Power Output (44v ~ 50v), Ideal for PoE+ Devices
attr -Key Feature 3 > Supports 100-Meter Transmission Distance
attr -Key Feature 4 > Works with IP Cameras, VoIP Phones, and Wi-Fi APs
attr -Key Feature 5 > Over-Current, Over-Voltage, Overload, and Anti-Interference Protection
CUDY PoE Injector
Model Version POE200 1.0
Protocols 802.3 Protocols:
- 802.3i 10 Mbps over Twisted Pair
- 802.3u 100 Mbps over Twisted Pair
- 802.3ab 1 Gbps over Twisted Pair
- 802.3af PoE
- 802.3at PoE
PoE Uplink Stream: 1× GbE
Downlink Stream: 1× GbE, 802.3at/af
Downlink Pin Assignment: Mode A

Transmission Distance:
- Cat. 5e or higher cable: 100 meters at Gigabit
- Note: Total cable length from the uplink switch through the PoE adapter to the downlink device is measured as one segment
Interfaces LED: Power
Power Input: AC Inlet
Power AC: 100-240V, 50/60Hz
Max Power Output: 30W
Reliability Power Protection:
- Surge Protection
- ESD Protection
- Overvoltage Protection
- Short-Circuit Protection

EMS: IEC/EN 61000-4-2, Level 3 ESD: Contact: 6kV; Air: 8kV
Grounding Methods: Three-Prong Plug

Environment:
- Ambient Operating Temperature: -10~45 ℃ (14~113 ℉)
- Storage Temperature: -40~70 ℃ (-40~158 ℉)
- Operating Humidity: 10%~95% non-condensing
- Storage Humidity: 5%~95% non-condensing
Certifications FCC, CE
Mechanical Installation:
- Desktop
- Wall-mount

Dimension:
- 121×50×36 mm
- 4.76×1.97×1.42 inches

Casing Material: Plastic
Package Content POE200
Power Cord
Mounting Kit
Installation Guide
Warranty 01-Year Brand Warranty
Description:

CUDY POE200 30W Gigabit PoE+ Injector

CUDY POE200 30W Gigabit PoE+ Injector is a handy and effective way to power your Ethernet connection. It is compatible with both IEEE 802.3af and 802.3at standards, which will make it work with most PoE and PoE+ devices such as IP cameras, VoIP phones, and wireless access points. This injector provides up to 30W of power through a single Ethernet cable, using 2-pair Mode A (pins 1/2 for negative and 3/6 for positive). It conveys data and power simultaneously through a single cable and transmits both up to 100 meters without the necessity of extra wiring or power outlets in hard-to-reach locations.

With one Gigabit Ethernet input and output, the POE200 boasts high-speed data transfer while powering your device. It also includes surge and ESD protection, which protects attached devices from power surges and noise interference. Built with a compact form factor, the POE200 boasts a power LED indicator for immediate status verification and is wall mountable for easy installation in domestic, office, or small business settings. CUDY POE200 30W Gigabit PoE+ Injector is a reliable choice to power your network devices and ensure uninterrupted data transmission. Simple installation, lower wiring cost, and wire-free performance for home and commercial use are its advantages.

Buy CUDY POE200 30W Gigabit PoE+ Injector in Bangladesh

You can buy your desired CUDY POE200 30W Gigabit PoE+ Injector at Global Brand PLC. We are the authorized distributor of CUDY in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
