CUDY GS1016E 16-Port Gigabit Light Managed Switch
CUDY GS1016E 16-Port Gigabit Light Managed Switch
CUDY GS1016E 16-Port Gigabit Light Managed Switch

CUDY GS1016E 16-Port Gigabit Light Managed Switch

Key Features of GS1016E:
16× GbE Port
Web Management, SNMP
VLAN (802.1Q/MTU/Voice/Port-Based)
Port Mirror, Static Aggregation, etc
Managed/VLAN/Extend Preset Modes
CUDY GS1016E 16-Port Gigabit Light Managed Switch
Based on 0 reviews. - Write a review
৳10,900.00
Add to Cart
Buy Now
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > 16× GbE Port
attr -Key Feature 2 > Web Management, SNMP
attr -Key Feature 3 > VLAN (802.1Q/MTU/Voice/Port-Based)
attr -Key Feature 4 > Port Mirror, Static Aggregation, etc
attr -Key Feature 5 > Managed/VLAN/Extend Preset Modes
Cudy Switch
Model GS1016E
Interfaces Gigabit RJ45 Ports: 16
Extend Mode Ports#1: ~#14
VLAN Mode Ports: #1~#14

LED:
Power
Speed/Link/ACT of Each Ethernet Port

Power Input: AC Inlet
Physical Buttons: Managed/VLAN/Extend DIP Switch
Power Basic Power Saving: True
Power Methods: AC
AC: 90~260V 50/60Hz
Max Power Consumption: 7.8W
Idle Power Consumption: 4.5W
Mechanical Dimension:
200×118×44 mm
7.87×4.65×1.73 inches

Product Weight: 625.5 g (22.06 oz.)
Casing Material: Metal

Installation:
Desktop
Rackmount via Brackets
Package Content GS1016E
Power Cord
Installation Guide
Mounting Kit
Performance Copper Speed and Distance:
Cat. 3 or higher cable: 100 meters at 10 Mbps
Cat. 5 or higher cable: 100 meters at 100 Mbps
Cat. 5e or higher cable: 100 meters at Gigabit
Cat. 5e or higher cable: 250 meters at 10 Mbps
Cat. 6 or higher cable: 150 meters at Gigabit

Copper Speed and Distance Note: 250-meter transmission is only available on the Extend Mode ports.
MAC Address Table: 8192
Max Switching Capacity: 32 Gbps
Jumbo Frame: 15 KB
Packet Buffer: 4 Mbit
Reliability Grounding Methods:
Three-Prong Plug
Grounding Point

ESD:
Contact: 6KV
Air: 8KV

Lightning/Surge Protection:
RJ45: 4KV AC: CM 4KV/DM 2KV

Environment:
Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5% ~ 90% non-condensing
Switching 802.3 Protocols:
802.3x Flow Control
802.3i 10BASE-T
802.3u 100BASE-TX
802.3ab 1000BASE-T
802.3az Power Saving

802.1 Protocols:
802.1d: STP
802.1w: RSTP
802.1p: LAN Layer 2 QoS/CoS
802.1q: VLAN Bridge Operation
802.1ab: LLDP/LLDP-MED

Port Management:
Port On/Off
Port Negotiation Speed
Port Trunk (Static Aggregation)
Port Mirror
Data Rate Limit
Jumbo Frame Settings
Storm Control
Traffic Monitor
MAC Address Management
EEE (802.3az)

Port Trunk Groups: 4
Max Port per Port Trunk Groups: 8

L2 Features:
IGMP Snooping
Loop Prevention
DHCP Snooping
STP/RSTP
LLDP Config and Neighbors
MTU VLAN
Port-Based VLAN
802.1Q VLAN
Voice VLAN
DSCP QoS
802.1p QoS
Port-Based QoS
System Control Methods:
Config Web Page
SNMP V1/V2

Firmware Upgrade: Local Upgrade
Reliability: Backup and Restore

Diagnostic Tools:
Cable Status/Length Diagnosis
Ping

Languages:
English
Bengali
German
Spanish
French
Portuguese
Russian
Arabic
Indonesian
Hindi
Urdu
Traditional Chinese
Simplified Chinese
Warranty 2-Year Brand Warranty
Description:

CUDY GS1016E 16-Port Gigabit Light Managed Switch

CUDY GS1016E 16-Port Gigabit Light Managed Switch provides reliable networking with 16 Gigabit Ethernet ports for high-speed data transfer. This switch supports web management and SNMP, making it simple to monitor and configure. It includes advanced features like VLAN (802.1Q/MTU/Voice/Port-Based) and QoS (802.1p/DSCP/Port-Based) to optimize traffic flow and enhance performance. Additional tools such as Port Mirror, Static Aggregation, STP/RSTP, and Loop Prevention ensure a stable and secure network environment.

The switch supports DHCP Snooping and IGMP Snooping for better security and multicast management. EEE (802.3az Power Saving) reduces energy usage during low-traffic periods. Managed, VLAN, and Extend preset modes make setup and customization easy. Designed for both desktop and rack-mount installations, the switch measures 200×118×44 mm (7.87×4.65×1.73'') and comes with a 2-year brand warranty. This is a practical choice for small and medium-sized networks needing efficient control and management.

Buy CUDY GS1016E 16-Port Gigabit Light Managed Switch in Bangladesh

You can buy your desired CUDY GS1016E 16-Port Gigabit Light Managed Switch at Global Brand PLC. We are the authorized distributor of CUDY in Bangladesh. You buy online and enjoy free home delivery. You can also visit any of our branches near you.
