CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point
CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point
CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point
CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point

CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point

Key Features of AP3000 Wall:
4-Stream Dual-Band Wi-Fi 6
2402 Mbps + 574 Mbps Wi-Fi
1.3 GHz Dual-Core CPU
Covers 60 m² (650 ft²) with up to 60 Devices Connected
PoE Passthrough, Watchdog, Schedule Reboot
CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point
Based on 0 reviews. - Write a review
৳0.00
Add to Cart
Specification Description Reviews
Specification:
Key Features
attr - Key Feature 1 > 4-Stream Dual-Band Wi-Fi 6
attr -Key Feature 2 > 2402 Mbps + 574 Mbps Wi-Fi
attr -Key Feature 3 > 1.3 GHz Dual-Core CPU
attr -Key Feature 4 > Covers 60 m² (650 ft²) with up to 60 Devices Connected
attr -Key Feature 5 > PoE Passthrough, Watchdog, Schedule Reboot
Hardware Specifications
CPU CPU Details: 1.3 GHz Dual-Core CPU
Memory/Storage Flash/ROM:
128 MB (1 Gbit) NAND

DDR/RAM:
256 MB (2 Gbit) DDR3
Wireless 5 GHz Wi-Fi Speed: 2402Mbps
2.4 GHz Wi-Fi Speed: 574 Mbps
5 GHz Wi-Fi Streams: 2T2R (2×2 MIMO) with an Extra Stream
2.4 GHz Wi-Fi Streams: 2T2R (2×2 MIMO)
Wi-Fi Antennas: 3× Internal
5 GHz Antenna Gain Max: 7.08dBi (US), 6.52dBi (EU)
2.4 GHz Antenna Gain Max: 3.17dBi

FEM or PA/LNA:
- 5 GHz: 3× Internal
- 2.4 GHz: 2× Internal

Beamforming: True
Range Performance: Max: 80 m (262 ft)
Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions.

Wall Performance:
Two wooden walls with thickness < 10 cm (4'')
One concrete wall with thickness < 20 cm (7'')
Interfaces Gigabit RJ45 Ports: 5
Ethernet Notes: The port on the back accepts PoE powering. One port on the front bottom supports PoE passthrough LED: System

Physical Buttons:
- Reset Button
- LED On/Off Button (Configurable to control LED and Wi-Fi)

Power Input: PoE via Ethernet Port
Power Power Methods:
- Passive PoE
- 802.3at/af PoE

Passive PoE: 48V
Max Power Consumption (W): 12 W (48 V PoE)
Idle Power Consumption (W): 5 W (48 V PoE)
Reliability Advanced: Hardware Watchdog
EMS: ESD: Contact: 4kV; Air: 8kV

Environment:
- Operating Temperature: 0 ℃ ~ 40 ℃ (14 ℉ ~149 ℉)
- Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
- Operating Humidity: 10% ~ 90% non-condensing
- Storage Humidity: 5% ~ 90% non-condensing
Mechanical Installation: Wall-mount
Dimension:
143×86×27.6 mm
5.63×3.39×1.09 inches

Product Weight: 298.6 g (10.53 oz.)
Software Specifications
Wireless Wi-Fi Standards: Wi-Fi 6
Max Wi-Fi Modulation: 1024-QAM

Wi-Fi Efficiency:
- OFDMA
- MU-MIMO
- BSS Color

Max Capacity: 256
Recommended Client Upper Limit: 60
Max Wi-Fi Channel Width: 160 MHz
Wi-Fi Security: WPA/WPA2/WPA3
Multi-SSID (Max Number): 8 SSIDs (Up to 4 SSIDs on each band)
General Operation Modes: Access Point
Mesh: Cudy Mesh

Mesh Backhaul:
- Wireless Backhaul
- Wired Backhaul

Multi-Band Backhaul: True
Network DHCP: Server
IP Versions: IPv4
IGMP: IGMP Snooping
Utilities Wake on LAN: True
Management All Devices Management: Wi-Fi Time Schedule
System LED Control: True
Local Control Method:
- Config Web Page
- App Control

Remote Control Method:
- Config Page via HTTPS
- App Control

Firmware Upgrade:
- Local Update
- App (Over the Air)
- Online Update

Reliability:
- Timed Reboot
- Backup and Restore

Diagnostic Tools:
- Diagnosis
- Ping
- Traceroute
- NSLookup
- System Log

Languages:
- English
- Bengali
- Catalan
- Czech
- German
- Greek
- Spanish
- French
- Hebrew
- Croatian
- Hungarian
- Italian
- Japanese
- Khmer
- Korean
- Dutch
- Norwegian
- Polish
- Portuguese
- Romanian
- Russian
- Slovak
- Swedish
- Thai
- Turkish
- Ukrainian
- Vietnamese
- Simplified Chinese
- Traditional Chinese
Dashboard Panel:
- Internet Status
- Mesh Status
- Device Management
- LAN Status
- Wi-Fi Status
- DHCP Server Status
- System Version
- Connected Devices

Charts:
- Mesh Topology
- Wi-Fi Speed
Additional
Included in the Box AP3000 Wall
Mounting Kit
Installation Guide
Certification FCC, CE
Description:

CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point Price in Bangladesh

CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point

CUDY AP3000 Wall AX3000 Dual Band Wall-Plate Wi-Fi 6 Access Point is a wireless in-wall access point for hotels, apartments, dorms, and office rooms. It provides strong, room-to-room coverage with dual-band Wi-Fi 6, supporting up to 60 connected devices across 60 square meters (650 square feet). Based on a 1.3 GHz dual-core processor, the AP3000 provides reliable and rapid performance. It is compatible with 4-stream dual-band Wi-Fi 6, which operates at up to 2402 Mbps on the 5 GHz band and 574 Mbps on 2.4 GHz. With 160 MHz bandwidth and 1024-QAM, it provides up to 2.5 times the speed of previous-generation Wi-Fi 5 APs, which makes it perfect for 4K streaming, online conferencing, and smart devices.

There are five Gigabit Ethernet ports on this device: 1× PoE in, 1× PoE out, and 3× standard LAN ports. The PoE passthrough lets you power another device like a VoIP phone, IP camera, or IPTV box without extra wiring. It supports 802.3af/at as well as passive PoE standards for streamlined installation. Designed for today's environments, the AP3000 features a low-profile, wall-mount design that easily integrates into any setting. It's ideal for room-based applications and prevents signal overlap while delivering each room or user an exclusive, high-speed connection.

With Watchdog support, scheduled reboot, and improved network functions, the AP is reliable and stays online with minimal human interaction. It is easy to install and manage, and is appropriate for both consumer and business settings. CUDY AP3000 Wall offers solid and easy Wi-Fi connection, perfect for rooms that need stable and secure internet by room, and accommodates multiple devices with intelligent network management.
